PFA insulated 4 wires RTD resistance thermometer wire - Twisted

Share to:
Model: PFA-PFA-4CU-24S
Number of cores: 4 cores
Wire size: 24AWG, 4*7/0.2MM, stranded
Conductor insulation: PFA
Jacket insulation: PFA
Type of wire: Twisted
Color: 2 red, 2 white, Jacket: white
Max. temperature: 260 ℃
Quantity:

Product Description

Features:
1) Continuous use up to 260
2) Short term use up to 315
3) Excellent chemical, abrasion and moisture resistance
4) Provides accurate temperature measure with high temperature stability
5) Test report is available

Model explanation:
 PFA-PFA-4CU-24S
1. Conductor insulation: PFA
2. Jacket insulation: PFA
3. No. of core: 4
4. Conductor: Silver-plated copper
5. Wire size: 24AWG, 4*7/0.20mm, Stranded
6. “S” means “ Stranded”, “Blank” means “ Solid”

Specifications:

Model no. PFA-PFA-4CU-24S
Conductor   Size 24AWG, 4*7/0.20MM, Stranded
Cross sectional area 0.22mm2
Construction Twisted
No. of core 4
Conductor insulation Material PFA
Thickness 0.20MM
Type Extruded
Color 2 Red, 2 White
Jacket insulation Material PFA
Thickness 0.30MM
Type Extruded
Color White
Outer diameter 3.1mm (+/-0.1mm)
Max. Operating temperature 260
Packing 100M -1000M per Roll or spool
(As required)
