Standard Size Round Pin 2 Pole Thermocouple Connector

Share to:

. Model No.: ZZ-S11
. Thermocouple calibration type: K, J, E, T, N, R/S
. Standard round pin male
. The max temperature up to 220°C
. The material of body: Thermoplastic
. Available in ANSI, IEC, JIS
. Accepts wires from 0.2 mm to 2.0 mm.
. Maximum cable diameter 8.0 mm.

Quantity:
  • ZZ-S11
  • ZONZEN
  • 853690000

Product Description

Standard Size Round Pin 2 Pole Thermocouple Connector

Specification

Order code Description Calibration Material of Pins Material of Body Max. temperature Color
(ANSI)
Positive (+) Negtive (-)
ZZ-S11-K Male+Female Type K NiCr NiAl Thermoplastic 220 Yellow
ZZ-S11-K-M Male Type K NiCr NiAl Thermoplastic 220 Yellow
ZZ-S11-K-F Female Type K NiCr NiAl Thermoplastic 220 Yellow
ZZ-S11-J Male+Female Type J Fe CuNi Thermoplastic 220 Black
ZZ-S11-J-M Male Type J Fe CuNi Thermoplastic 220 Black
ZZ-S11-J-F Female Type J Fe CuNi Thermoplastic 220 Black
ZZ-S11-T Male+Female Type T Cu CuNi Thermoplastic 220 Blue
ZZ-S11-T-M Male Type T Cu CuNi Thermoplastic 220 Blue
ZZ-S11-T-F Female Type T Cu CuNi Thermoplastic 220 Blue
ZZ-S11-E Male+Female Type E NiCr CuNi Thermoplastic 220 Violet
ZZ-S11-E-M Male Type E NiCr CuNi Thermoplastic 220 Violet
ZZ-S11-E-F Female Type E NiCr CuNi Thermoplastic 220 Violet
ZZ-S11-N Male+Female Type N NiCrSi NiSiMg Thermoplastic 220 Orange
ZZ-S11-N-M Male Type N NiCrSi NiSiMg Thermoplastic 220 Orange
ZZ-S11-N-F Female Type N NiCrSi NiSiMg Thermoplastic 220 Orange
ZZ-S11-S Male+Female Type S Cu CuNi Thermoplastic 220 Green
ZZ-S11-S-M Male Type S Cu CuNi Thermoplastic 220 Green
ZZ-S11-S-F Female Type S Cu CuNi Thermoplastic 220 Green


Dimension

QQ截图20190510133950

Product Pictures

Type K (ANSI)
ZZ-S11-KX (空心,正面) ZZ-S11-KX (空心,侧面) ZZ-S11-KX (空心,插针)
Type K (IEC)
ZZ-S11-KX (空心,绿色,正面) ZZ-S11-KX (空心,侧面,绿色) ZZ-S11-KX (空心,上面,绿色)

Type K (Thermocouple type)
褐色 ZZ-S11-KX (空心,正面) 褐色 ZZ-S11-KX (空心,分开) 褐色 ZZ-S11-KX (空心,反面)

Type J
ZZ-S11-JX (空心,插针) ZZ-S11-JX (空心) ZZ-S11-JX (空心,侧面)
